10.5.3 Test the brine pump
1. Start the brine pump by setting the parameter BRINE PUMP to a value between 30% and 100%. (1 at constant speed circulation
pump).
2. Check that the brine pump is running by:
▪
listening
▪
putting a hand on the pump
▪
checking that the level in the bleed and expansion vessel (111) is stable (Brine/Water). If the level is not stable there is air in the
system.
▪
listen for air
▪
If a constant speed circulation pump does not start automatically, perform manual start as below.
▪
If there is air in the brine system, bleed, see chapter Filling and bleeding the brine system.
3. Stop the brine pump by setting the parameter BRINE PUMP to 0.
10.5.4
Test the heating system circulation pump
1. Start the heating system circulation pump by setting the parameter CIRC. PUMP to a value between 30% and 100%. (1 at constant
speed circulation pump).
2. Check that the circulation pump is running by carrying out the following:
▪
Listen
▪
Place a hand on the pump
▪
Listen for air
3. If a constant speed circulation pump does not start, perform a manual start:
1. Open and remove the bleed screw (1) on the front of the pump. Ensure
to catch the water that runs out when the screw is removed.
2. Insert a flat blade screwdriver and turn it in the direction of rotation of
the pump (clockwise).
3. Reinstall the bleed screw with its rubber seal.
4. If there is air in the heating system, bleed, see Filling and bleeding the water heater and heating system.
5. Stop the circulation pump by setting the parameter CIRC. PUMP to 0.
10.5.5
Test the valve for hot water production
Reversing valve
1. Activate the reversing valve by setting the parameter REV.V. HOT WATER to 1.
2. Check that the indicator on the exchange valve's upper side changes position.
3. Stop the test by setting the parameter REV.V. HOT WATER to 0.
Installation Guide Domestic heat pumps
Danfoss Heating Solutions VMGFQ102
57
