R13 B hardware
3
4
5
6
7
8
9
10
11
12
3. Multiband antenna
4. RS232/RS485 socket
5. Power supply
6. LR13 logic board
7. Data logger connector
8. INXX card socket
9. External EEPROM
10. Signal LEDs
11. TR800-CE MCX radio
12. Wiring connection
User Manual
R13 B Receiver
Technical description
©
Danfoss | January 2019 BC292365780571en-000101 | 7
