The following must be programmed in order shown - see explanation of settings in the Operating Instructions:
Function:
Parameter no. Setting Data value no.
Activation of process controller 100
Speed control, closed loop
[1]
Feedback signal 314
Feedback signal
[2]
Terminal 32 306 Encoder feedback, input B [24]
Terminal 33 307 Encoder feedback, input A [25]
Minimum feedback 414 0 rpm
Maximum feedback 415 1650 rpm (max. ref. + 10%)
Reference 308
Reference (factory setting)
[1]
Terminal 53, min. scale 309 0 Volt (factory setting)
Terminal 53, max. scale 310 10 Volt (factory setting)
Minimum reference 204 0 rpm
Maximum reference 205 1500 rpm
Min. speed 201 0 Hz
Max. speed 202 75 Hz
Proportional gain 417
Application-dependent
Integration time 418
Application-dependent
Differentiation time 419
Application-dependent
VLT
®
5000 Design Guide
108 MG.52.B2.02 - VLT
®
