Danfoss VLT 5027 Design Guide

PNU
#
Parameter description Factory setting Range
Changes
during
operation
4-Setup
Conversion
index
Data
type
300
Terminal 16, input Reset Yes Yes 0 5
301 Terminal 17, input Freeze reference Yes Yes 0 5
302 Terminal 18 Start, input Start Yes Yes 0 5
303 Terminal 19, input Reversing Yes Yes 0 5
304 Terminal 27, input Coasting stop, inverse Yes Yes 0 5
305 Terminal 29, input Jog Yes Yes 0 5
306 Terminal 32, input Choice of setup, msb/speed up Yes Yes 0 5
307 Terminal 33, input Choice of setup, lsb/speed down Yes Yes 0 5
308 Terminal 53, analogue input voltage Reference Yes Yes 0 5
309 Terminal 53, min. scaling 0.0 V 0.0 - 10.0 V Yes Yes -1 5
310 Terminal 53, max. scaling 10.0 V 0.0 - 10.0 V Yes Yes -1 5
311 Terminal 54, analogue input voltage No operation Yes Yes 0 5
312 Terminal 54, min. scaling 0.0 V 0.0 - 10.0 V Yes Yes -1 5
313 Terminal 54, max. scaling 10.0 V 0.0 - 10.0 V Yes Yes -1 5
314 Terminal 60, analogue input current Reference Yes Yes 0 5
315 Terminal 60, min. scaling 0.0 mA 0.0 - 20.0 mA Yes Yes -4 5
316 Terminal 60, max. scaling 20.0 mA 0.0 - 20.0 mA Yes Yes -4 5
317 Time out 10 sec. 1 - 99 sec. Yes Yes 0 5
318 Function after time out Off Yes Yes 0 5
319 Terminal 42, output 0 - I
MAX
Þ 0-20 mA Yes Yes 0 5
320 Terminal 42, output, pulse scaling 5000 Hz 1 - 32000 Hz Yes Yes 0 6
321 Terminal 45, output 0 - f
MAX
Þ 0-20 mA Yes Yes 0 5
322 Terminal 45, output, pulse scaling 5000 Hz 1 - 32000 Hz Yes Yes 0 6
323 Relay 01, output Ready - no thermal warning Yes Yes 0 5
324 Relay 01, ON delay 0.00 sec. 0.00 - 600 sec. Yes Yes -2 6
325 Relay 01, OFF delay 0.00 sec. 0.00 - 600 sec. Yes Yes -2 6
326 Relay 04, output Ready - remote control Yes Yes 0 5
327 Pulse reference, max. frequency 5000 Hz Yes Yes 0 6
328 Pulse feedback, max. frequency 25000 Hz Yes Yes 0 6
329 Encoder feedback pulse/rev. 1024 pulses/rev. 1 - 4096 pulses/
rev.
Yes Yes 0 6
330 Freeze reference/output function No operation Yes No 0 5
345 Encoder loss timeout 1 sec. 0 - 60 sec Yes Yes -1 6
346 Encoder loss function OFF Yes Yes 0 5
357 Terminal 42, Output minimum scaling 0 % 000 - 100% Yes Yes 0 6
358 Terminal 42, Output maximum scaling 100% 000 - 500% Yes Yes 0 6
359 Terminal 45, Output minimum scaling 0 % 000 - 100% Yes Yes 0 6
360 Terminal 45, Output maximum scaling 100% 000 - 500% Yes Yes 0 6
361 Encoder loss threshold 300% 000 - 600 % Yes Yes 0 6
VLT
®
5000 Design Guide
134 MG.52.B2.02 - VLT
®
is a registered Danfoss trademark
