SERIES 1500 LIQUID TURBINE METER
• All Daniel Series 1500 Liquid Turbine Meters have, as standard, the LME which is fitted
with two pickoffs and a dual channel preamplifier.
• The pickoff mountings are oriented so that the outputs from the pickups are 90º
electrically out of phase. The turbine meter may be supplied with two LMEs, offering up
to four pulse outputs. Alternate pairs across the two LMEs are also 90º electrically out of
phase.
• Each turbine meter is precisely flow calibrated before shipment.
1.2.3 Parts lists for the Series 1500 LTM, Nominal Pipe Size
(NPS) 3-24
This section includes the necessary parts required to assemble a standard unit described in
this manual.
Configurations for LME assembly - Standard enclosure, LME assembly - High temperature ,
RME assembly - Pipe mount and RME assembly - Wall mount are shown below.
User manual Introduction
P/N 3-9008-515 March 2019
