SERIES 1500 LIQUID TURBINE METER
Table 1-15: Part description for an NPS 20 unidirectional LTM
Item
number
Description Part number for
material 304 SS
Quantity
required
14 O-ring 1500093-022 1
40 Meter housing Consult factory 1
41 Pickoff 899-00-201-00 2
42 Anti-rotation bracket clamp 899-10-230-66 1
53 Thrust washer 1-504-05-124 2
54 Shaft 1-504-05-662 1
60 Nut 1-561-76-089 2
62 Upstream cone 1-307-10-492 1
65 Downstream cone 1-307-10-592 1
68 Housing insert 1-307-03-110 1
69 Hanger blades 1-307-10-775 6
70 Cotter pin 1-562-05-659 2
71 Hanger hub 1-307-10-698 2
72 Rotor assembly 1-504-05-662 1
Note
For material 316 SS part numbers, consult the factory.
Table 1-16: Part description for an NPS 24 unidirectional LTM
Item
number
Description Part number for
material 304 SS
Quantity
required
14 O-ring 1500093-022 1
40 Meter housing Consult factory 1
41 Pickoff 899-00-201-00 2
42 Anti-rotation bracket clamp 899-10-230-66 1
53 Thrust washer 1-504-05-125 2
54 Shaft 1-504-05-667 1
60 Nut 1-561-76-090 2
62 Upstream cone 1-307-10-493 1
65 Downstream cone 1-307-10-593 1
68 Housing insert 1-307-03-111 1
69 Hanger blades 1-307-10-780 6
70 Cotter pin 1-562-05-665 2
71 Hanger hub 1-307-10-700 2
