SERIES 1500 LIQUID TURBINE METER
Meter housing internal components - NPS 3 through 8 -
Bidirectional
The figure below identifies and describes the NPS 3 through 8 bidirectional meter housing
components.
Figure 1-9: Part identification for an NPS 3 through 8 bidirectional (blade or rimmed)
LTM
