36
www.Daniel.com
SERIES 1500 LIQUID TURBINE METER
Table 1-19: Part description for an NPS 6 bidirectional LTM
Item
number
Description Part number for
material 304 SS
Part number for
material 316 SS
Quantity
required
14 O-ring 1500093-022 1500093-022 1
40 Meter housing Consult factory Consult factory 1
41 Pickoff 899-00-201-00 899-00-201-00 2
42 Anti-rotation bracket clamp 899-10-230-66 899-10-230-66 1
53 Thrust washer 1-504-05-117 1-504-05-117 2
54 Shaft 1-504-05-632 1-504-05-632 1
55 Bladed rotor 1-307-11-400 1-307-11-401 1
60 Nut 1-561-76-163 1-561-76-163 2
62 Upstream cone-rimmed 1-307-10-445 1-307-10-446 2
Upstream cone-bladed 1-307-10-447 1-307-10-448 2
68 Housing insert 1-307-03-003 1-307-03-023 2
69 Hanger blades 1-307-10-745 1-307-10-746 6
71 Hanger hub 1-307-10-645 1-307-10-646 2
72 Rimmed rotor 1-307-11-402 1-307-11-403 1
Table 1-20: Part description for an NPS 8 bidirectional LTM
Item
number
Description Part number for
material 304 SS
Part number for
material 316 SS
Quantity
required
14 O-ring 15000093-022 15000093-022 1
40 Meter housing Consult factory Consult factory 1
41 Pickoff 899-00-201-00 899-00-201-00 2
42 Anti-rotation bracket clamp 899-10-230-66 899-10-230-66 1
53 Thrust washer 1-504-05-118 1-504-05-118 2
54 Shaft 1-504-05-637 1-504-05-637 1
60 Nut 1-561-76-171 1-561-76-171 2
62 Upstream cone-rimmed 1-307-10-450 1-307-10-451 2
68 Housing insert 1-307-03-004 1-307-03-024 2
69 Hanger blades 1-307-10-750 1-307-10-751 6
71 Hanger hub 1-307-10-650 1-307-10-651 2
72 Rimmed rotor 1-307-11-404 1-307-11-405 1
User manual Introduction
P/N 3-9008-515 March 2019
User manual 39
