55
www.Daniel.com
USER MANUAL
Safety precautions using appropriately rated lifting slings
When lifting a liquid turbine meter by itself, Daniel recommends using lifting slings
appropriately positioned at designated areas of the turbine meter.
WARNING
LIFTING HAZARD
The lifting instructions are for installation and removal of the Daniel Liquid Turbine
Meter only and do not address lifting the turbine meter while it is attached or bolted to
piping.
Failure to comply with these instructions may result in death, serious injury, or
equipment damage.
Read and follow the safety precautions listed below.
Never attempt to lift the turbine meter by wrapping slings around the electronics
enclosure.
Never attempt to lift the turbine meter using only one sling around the turbine meter.
Always use two slings wrapped around each end of the body (refer to Figure 4-1). A
choker style sling with a spreader bar is recommended.
Figure 4-1: Correct sling attachment
Prior to use, visually inspect the slings for any signs of abrasion or other damage. Refer
to the sling manufacturer for inspection procedure specific to the sling you are using.
User manual Prepare the turbine meter for use
P/N 3-9008-515 March 2019
User manual 59
