4
Description of the device
Features
The DS-600 is a CD-Player from DAP Audio.
• LCD Display with blue backlight
• Full function infrared remote control
• Pitch control
• Anti shock system ( 20 seconds)
• Play modes: Single, Continue, Program, Repeat.
• Stereo output RCA
• Slot loading running gear
Overview Frontside
Backside
1) POWER ON / OFF 14) Pitch Level
2) DISC HOLDER 15) Cue Level
3) B.SKIP 16) Master Level
4) F.SKIP 17) PLAY/PAUSE
5) 10 (Track+10 Button) 18) REV
6) CUE 19) FWD
7) TIME 20) PITCH-Button
8) PROG 21) Phones
9) SEL 22) Line Out L / R
10) Repeat 23) Rec Out L / R
11) Remote sensor 24) 115V/230V Switch
12) LCD (Liquid Crystal Display) 25) Fuse
13) OPEN/CLOSE (Open/Close Button) 26) AC Powercable
