6
Allowed changes in your electrical system to be carried out only
by qualified electricians.
!
Caution
When ALTW T-connector & trunk cable are used, an additional
heat-shrinkable tubing have to be applied.
!
Caution
Lightning surge suppression- Lightning does not actually need
to strike the equipment or building where the PV system is
installed to cause damage. Often, a strike nearby will induce
voltage spikes in the electrical grid that can damage equipment.
Darfon’ s Micro inverters (MIG240UL00) have integral surge
protection, much higher than most traditional inverters. However,
if the surge has sufficient energy, the built- in protection in the
device would exceed, and the device can be damaged.
As the Darfon Limited Warranty does not cover “extraordinary
and unexpected manifestation of the forces of nature,” such as
lightning strikes, therefore it is recommended to install surge
protection as part of any solar installation.
We recommend the following protection devices. These have
7
been tested to ensure that they do not interfere with power line
communications. Install per vendor instructions.
Residential:
Vendor: Citel, Part Number DS72RS-120 Application: Residential 120/240V
Split Phase where N-G bond exists.
Commercial:
Vendor : Citel, Part Number SP-120
Application: Branch panel protection
See the vendor datasheet for DS70R, (which includes the DS72RS-120) or
for SP-120 at
h
ttp://www.citelprotection.com/english/citel_data_sheets/ac_protection/
