DARLEY ZSP - 26 - dzd0035.pdf (p.104); Sheet 1; new_view_1; left_2

APPR'D
CHG NO.DATEDESCRIPTIONLTR
REVISIONS
DO NOT SCALE PRINT
INCHES UNLESS NOTED
ALL DIMENSIONS IN
REPRODUCTION IS PROHIBITED
W.S. DARLEY AND CO. - UNAUTHORIZED
THIS DESIGN IS THE PROPERTY OF
MATERIAL DESCRIPTION:
PATTERN NO.MATERIAL NO.
OLD PART NO.
INCH
THIRD ANGLE PROJECTION
DATE
SCALE
CHKD
DR'N
TRCD
EXCEPT
AS NOTED
.00 .03
.000 .010
ANGLES 1
TOLERANCE
ITASCA, IL - CHIPPEWA FALLS, WI
W.S. Darley & Co.
[MILLIMETER]
REMOVE SHARP EDGES
MDL CREATED
SHEET
MODEL NAME
11.75
[298,5]
10.63
[270]
8.16
[207,1]
10.59
[268,9]
14.00
[355,6]
25.28
[642]
8.00
[203,2]
SUCTION
24.43
[620,4]
33.42
[848,9]
6.91
[175,4]
9.59
[243,6]
10.155
[257,94]
5.080
[129,03]
8.580
[217,93]
9.025
[229,24]
6.79
[172,4]
8.11
[206]
16.32
[414,4]
10.63
[270]
7.59
[192,8]
11.75
[298,5]
(4) .53
[13,5]
DWG - ZSP, INPUT LEFT
CROSS SECTION
15-Jul-14
DZD0035
1/4
SMS
WAH
DZD0035 10JUL2014
1/1 D
AS LISTED
OPTIONAL PUMP CASING POSITIONS
DISCHARGE CENTERED TO SUCTION
APPROXIMATE WEIGHT 690 LBS [312 KG]
1/4-18 NPT SCREENED
DISCHARGE PORT
(3) 1/4-18 NPT
DISCHARGE PRESSURE PORTS
(2) 3/8-18 NPT
HEATER CORE PORTS
(12) 1/2-13 UNC-2B
1.00 THR'D
ON 10.375 BC
3/4-14 NPT X 3/4 JIC
MALE PRIMER PORT
GEAR CASE OIL FILL/VENT
TRANSMISSION OIL
LEVEL DIPSTICK
STANDARD SCREWDRIVER
TO REMOVE
1550 COMPANION FLANGE
MAGNETIC OIL DRAIN PLUG
7/8" WRENCH OR SOCKET
TO REMOVE
6.00
[152.4]
DISCHARGE
(8) 1/2-13 UNC-2B TAP
.75 THR'D
ON 8.500 BC
DARLEY 12VDC OR 24 VDC
BELT DRIVEN PRIMER
(SPECIFY REQUIRED VOLTAGE)
SCALE 1/8
REMOTE MOUNT PRIMER AND TANK CONTROL SWITCH
9 O'CLOCK DISCHARGE 6 O'CLOCK DISCHARGE 3 O'CLOCK DISCHARGE
