5.0 PRODUCT OVERVIEW
FRONT CAMERA
1. Mini USB connector
(for power)
2. Reset button
3. Micro USB Connector
(Connect to rear cam)
4. SD card Slot
5. Adhesive Sticker
6. Speaker Hole
7. Camera Lens
8. Recording indicator LED
9. Power button/WIFI ON
and OFF/Lock ile
10. Microphone
REAR CAMERA
1. Micro USB Connector
(Connect to Front Cam)
2. Adhesive Sticker
3. Camera Lens
4. Mirror Image Switch
1 3
2
4
7651
4
3 98
10
2
