Portable Desktop Mounting
QUICK REFERENCE GUIDE 7
2. Remove the adhesive strips protecting the mounting tabs on the base sta-
tion.
3. Align the base station with the mounting plate until you see the sphere
inside the bigger hole on the left.
Protective Strips
