Datalogic SE-SR2 User Manual

SE-SR2
Operating instructions SE-SR2
826002433-EN-Rev.C
14
Relay outputs
Utilisation category of auxiliary contacts
AC15 at 230 V
Max. current 3 A
DC13 (6 cycles/min) at 24 V
Max. current 4 A
Utilisation category in accordance with UL
Voltage 250 V AC G.U. (same polarity)
With current 6 A
Voltage 24 V DC G. U.
With current 6 A
Pilot Duty B300, R300
External contact fuse protection, safety contacts
In accordance with the standard EN 60947-5-1
Max. melting integral 66 A²s
Blow-out fuse, quick 6 A
Blow-out fuse, slow 4 A
Blow-out fuse, gG 6 A
Circuit breaker 24V AC/DC, characteristic B/C 4 A
External contact fuse protection, auxiliary contacts
Max. melting integral 66 A²s
Blow-out fuse, quick 6 A
Blow-out fuse, slow 4 A
Blow-out fuse, gG 6 A
Circuit breaker 24 V AC/DC, characteristic B/C 4 A
Contact material AgSnO2 + 0,2 µm Au
Conventional thermal current while loading sev-
eral contacts
Ith per contact at UB DC; AC1:240V,DC1:24V
Conv. therm. current with 1 contact 6 A
Conv. therm. current with 2 contacts 6 A
Conv. therm. current with 3 contacts 4,5 A
Times
Switch-on delay
With automatic start typ. 200 ms
With automatic start max. 400 ms
With manual start typ. 100 ms
With manual start max. 400 ms
With monitored start typ. 30 ms
With monitored start max. 50 ms
Delay-on de-energisation
With E-STOP typ. 10 ms
With E-STOP max. 20 ms
With power failure typ. 70 ms
With power failure max. 120 ms
