Appendix F – Bar Code Summary Data
Class Series 2 Programmer’s Manual 203
Font
203 DPI Resolutions 300 DPI Resolutions 400 DPI Resolutions 600 DPI Resolutions
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
K .40 5:2 .40 9:4 .40 10:4 .40 15:6
L 1.30 5:2 1.30 9:4 1.30 10:4 1.30 15:6
M .90 3 .90 4 .90 6 .90 9
N .80 3 .80 4 .80 6 .80 9
O .40 6:3 .40 8:4 .40 12:6 .40 18:9
p .08 N/A .08 N/A .08 N/A .08 N/A
Q 1.40 2 1.40 4 1.40 4 1.40 6
R 1.40 2 1.40 4 1.40 4 1.40 6
S 1.40 2 1.40 3 1.40 4 1.40 6
T .80 1 .80 1 .80 2 .80 3
U/u 1.00 N/A 1.00 N/A 1.00 N/A 1.00 N/A
v .5 1 .5 1 .5 2 .5 3
z N/A N/A N/A N/A N/A N/A N/A N/A
Z/z N/A N/A N/A N/A N/A N/A N/A N/A
W1C/W1c N/A N/A N/A N/A N/A N/A N/A N/A
W1D/W1d N/A N/A N/A N/A N/A N/A N/A N/A
W1F/W1f N/A N/A N/A N/A N/A N/A N/A N/A
W1G/W1g .5 5:2 .5 7:3 .5 9:4 .5 14:6
W1I .40 2 .40 4 .40 4 .40 6
W1J .40 2 .40 4 .40 4 .40 6
W1k N/A 2 N/A 3 N/A 4 N/A 6
W1L 0.80 N/A 0.80 N/A 0.80 N/A 0.80 N/A
W1M/W1m N/A N/A N/A N/A N/A N/A N/A N/A
W1N/ W1n 0.40 6:2 0.40 9:4 0.40 12:4 0.40 18:6
(continued)
