Appendix F – Bar Code Summary Data
202 Class Series 2 Programmer’s Manual
Bar
Code ID
Symbology Length Checksum
Valid ASCII Characters, decimal value
representation
Linear
Scanner
Supported
W1Y / W1y Code 16K Varies Yes All ASCII characters
W1z MicroPDF417 Varies Yes All 8-bit values
W1Z MicroPDF417 w/ Byte Count Specified Yes All 8-bit values
[1]
Readable when using “Barcode Count” method (see <STX>KcSN for details).
[2]
Available for display-equipped and EX2 models only.
Table F-1: Bar Code Characteristics
Bar Code Default Widths and Heights
Bar Code Default Data
Font
203 DPI Resolutions 300 DPI Resolutions 400 DPI Resolutions 600 DPI Resolutions
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
Height
(inches)
Ratio/
Module Size
A .40 6:2 .40 9:4 .40 12:4 .40 18:6
B .80 3 .80 4 .80 6 .80 9
C .80 3 .80 4 .80 6 .80 9
D .40 5:2 .40 9:4 .40 10:4 .40 15:6
E .40 2 .40 4 .40 4 .40 6
F .80 3 .80 4 .80 6 .80 9
G .80 3 .80 4 .80 6 .80 9
H .40 6:2 .40 9:4 .40 12:4 .40 18:6
I .40 6:3 .40 9:4 .40 12:6 .40 18:6
J .40 5:2 .40 9:4 .40 10:4 .40 15:6
(continued)
