Datapath VisionLC Series User Manual

The VisionLC range of “Live Capture” cards provide single and dual channel high denition capture channels in a PCIe low
prole card. The full range of LC capture cards include:
VisionLC-HD - Single channel, high denition HDMI live capture card
VisionLC-HD2 - Dual channel, high denition HDMI live capture card
VisionLC-SDI - Single channel, SDI live capture card
Datapath’s LiveStream Capture architecture allows captured video to be processed and delivered in real time to a processor or
graphics card. The VisionLC range of cards support on board colour space conversion and scaling, providing the ability to
eciently transfer the video signal in a suitable format for rendering or encoding applications. The VisionLC range natively
supports 32, 24, 16 and 12 bit YUV and RGB formats.
The VisionLC range has been designed specically for use within smaller applications:
• Medical operating theatres
• Simulation systems
• Lecture capture
• Real time Streaming
• Videoconferencing
3
Introduction
You are likely to need a at blade and /or a cross head screwdriver for the installation of your VisionLC card; it would be useful to
have these to hand before you begin.
• Power down the PC (including peripherals), switch o at the mains and disconnect all the cables
connected to the computer, noting the positions for accurate re-connection
• Remove the PC cover
• Locate a vacant PCI Express slot (x4 physical or higher) on the motherboard and remove the blanking plate (retain all
screws)
If you are in doubt consult your motherboard documentation to correctly identify a PCI Express slot.
• Reconnect all cables to the PC then connect HDMI or SDI cables (not supplied) distributing the signal to the connections on
your VisionLC card
• Power up the PC and commence the software installation.
Connecting Input Sources
Never use force when connecting cables to your VisionLC card as it could cause damage to the connector on the card and in
turn, damage the card itself which is not covered under warranty.
Installing the Capture Card

Datapath VisionLC Series Specifications

General

Brand	Datapath
Model	VisionLC Series
Category	PCI Card
Language	English
