22
Selectable Video Standards
NTSC/PAL
DV Input
Three 6-PIN IEEE1394 Fire Wire Ports with
DC12V Bus Power supported
Supports DV25, NTSC 4:1:1, PAL 4:2:0
Analog Video Input/Output
Composite (CVBS): 1.0 Vp-p 75 ohm BNC.
S-Video(Y/C): 4-pin 75 ohm DIN Plug
Y: 1Vpp, 75 ohm
C: 0.286Vpp, 75 ohm
Component YUV: Betacam standard, Y, Cr, Cb
75 ohm BNC
Black Burst Output: 75 ohm BNC connector
DV Audio
2-Channel Locked / Unlocked Option
Analog audio
Unbalanced Audio L/R in & Out RCA Ch1/2
Balanced XLR audio in and out Ch1/2
Level: 6 Vp-p
Bandwidth: 20HZ ~ 20KHZ
S/N Ratio: >55 dB, THD: <0.3%
Device Control
D-SUB 9-pin (female) RS-232A interface
Supports remote control front panel function
Dimensions / Weight
8” x 9.8” x 5.2”
203 mm x 249 mm x 132 mm
Weight 8 lbs / 3.6kg
Power Input
DC 12V, 4.2Amp
Supports Disc.
