BLUEPAD-55 V2 USER GUIDE
Page 12 of 23
Device Operation
Figure 1
1. Contactless LEDs status indications
2. LCD Display with touchscreen
3. Keypad
4. Charging pads for charging station
5. Chip chard reader
6. USB connector
7. SIM/SAM card tray
8. Charging pads and UART communication (for Docking stations)
