EN DATEQ BCS50 user manual Introduction 3
Introduction
The DATEQ BCS50 mixer-series is especially developed to be used in a broadcast-
environment. The large number of built-in automations makes this mixer ideally suited in any
self-supporting studio.
Frame
The BCS50 mixer is a modular system existing of a frame, a master module and free to
choose input-modules. The frame can contain up to 16 input modules and a master module.
The power-supply is built into the frame.
Input modules
A large number of input modules is available:
Type
number
Possible connections Connector
type
BCS51 MIC Microphone XLR-F
LINE Balanced mono line XLR-F
BCS51E As BCS51, but with three-way tone control
BCS52 LINE 1 Unbalanced stereo line (RIAA optional) XLR-F
LINE 2 Unbalanced stereo line XLR-F
BCS52E As BCS52, but with three-way tone control
BCS52S LINE 1 Balanced stereo line 2x 6.3mm jack
LINE 2 Balanced stereo line (RIAA optional) 2x 6.3mm jack
BCS52SE As BCS52S, but with three-way tone control
BCS52N LINE 1 Balanced stereo line 2x XLR-F
LINE 2 Balanced stereo line 2x 6.3mm jack
BCS52NE As BCS52S, but with three-way tone control
BCS53 Telephone module with built-in analogue telephone
hybrid
1x XLR
1x XLR-M
BCS53T Telephone module to connect an external (digital)
telephone hybrid
SUB-D-15
The position and the number of modules is variable. The only limitation is the number of
analogue telephone hybrids that can be used simultaneously (maximum 2 or 3, depending on
the quality of the subscriber line).
When digital telephone hybrids are used more than 2 lines can be on the air simultaneously.
This is because digital hybrids have a better trans-hybrid attenuation.
Mastermodule
The BCS50 mastermodule has all the mix,- and output amplifiers and various volume-
controls. This module is placed at the most right position in the frame.
Meterbridges
The BCS50 meterbridge can house the following readouts:
• BCS121: DCF77 atomic-clock/ timer/ stopwatch
• Analogue moving-coil meter, or 2x 50 segment digital horizontal LED VU meter with peak
indicator
• BCS68: dual 2x 30 segment digital vertical LED VU meter with peak indicator
