EN DATEQ BCS50 user manual BCS50 Technical specifications 39
BCS53
PHONE LINE.......................................................................standard subscriber line, XLR-F (in) and XLR-M (out)
Signal level...............................................................-21 .. -0 dBm
Input impedance......................................................600 ohm
BCS53T
TELOS
Signal level...............................................................-15 .. +6 dBm
Input impedance......................................................10 kohm
Output impedance...................................................10 kohm
BCS58
INPUTS
AIR ....................................................................................unbalanced, 6.3mm stereo jack
Signal level...............................................................-15 ... +6 dBm
Input impedance......................................................10 kohm
SPARE1 and SPARE2......................................................unbalanced, 6.3mm stereo jack
Signal level...............................................................0 dBm
Input impedance......................................................10 kohm
TALKBACK.........................................................................unbalanced, 6.3mm stereo jack
Signal level...............................................................0 dBm
Input impedance......................................................10 kohm
PGM INSERT......................................................................unbalanced, 6.3mm stereo jack
Signal level...............................................................0 dBm
Input impedance......................................................10 kohm
OUTPUTS
PGM-L, PGM-R and MONO..............................................electronically balanced, XLR-M
Signal level...............................................................+6dBm @ 600 ohm
Output impedance...................................................600 ohm
AUD, AUX, PGM1-3, CR, STUDIO...................................unbalanced stereo, 6.3mm stereo jack
Signal level...............................................................0dBm
Output impedance...................................................600 ohm
ANN. and GUEST...............................................................headphones, 6.3mm stereo jack
Power.........................................................................0.3W @ 4 ohm
Impedance................................................................3 ... 32 ohm
EXT. METER.......................................................................SUB-D-15-F
Signal level...............................................................0dBm
Output impedance...................................................1 kohm
PGM INSERT......................................................................6.3mm stereo jack
Signal level...............................................................0dBm
Output impedance...................................................600 ohm
ON-AIR1 and ON-AIR2.....................................................6.3mm stereo jack
Control voltage.........................................................12V
Impedance................................................................1 kohm
COMMON
Overload indication.................................................+18dBm
Output noise.............................................................<-100dBm (all inputs off)
<-80dBm (all inputs on)
SUPPLY
Mains input...............................................................115Vac or 230Vac; internally switchable
Power.........................................................................100VA
Fuse...........................................................................2 A slow 5x20mm
