Dateq LPM 7.3 Manual Technical specifications
EN
Technical specifications
MONO Inputs
MIC (channel 1..7) ........................................... XLR-3 female, electronically balanced
Signal level.............................................-54 dB @ 600 Ohm variable
Impedance..............................................3 kOhm nominal
Input noise..............................................< -107 dB (IHF-A)
Headroom...............................................+20 dB
STEREO Inputs
DISC (Channel 3, 4 and 5)............................... Cinch
Signal level.............................................-42 dB @ 47 kOhm variable
Impedance..............................................47 kOhm/ 25pF nominal
Input noise..............................................< -80 dB (IHF-A)
Channel separation.................................> 76 dB @ 1 kHz
LINE (channel 1..7) ......................................... Cinch
Signal level.............................................0 dB @ 600 Ohm variable
Impedance..............................................10 kOhm nominal
Input noise..............................................< -80 dB (IHF-A)
Channel separation.................................> 80 dB @ 1 kHz
TONE CONTROL
High........................................................12 kHz ±12 dB, Shelving
Mid..........................................................1400 Hz ±12 dB, Bell
Low.........................................................50 Hz ±15 dB, Shelving
OUTPUTS
MASTER (XLR)................................................ +6 dB balanced/ 600 Ohm/ variable
MASTER OUT / MONITOR/PFL (Cinch) ......... 0 dB unbalanced/ 600 Ohm/ variable
REC (Cinch)..................................................... 0 dB unbalanced/ 600 Ohm/ fixed
STEREO EFFECT SEND (Cinch).................... 0 dB unbalanced/ 600 Ohm/ postfader
PHONES (6,3 mm TRS Jack).......................... 0,3 W @ 4 Ohm/ Impedance 4..32 Ohm
FREQUENCY RESPONCE
Input to Master ................................................. 20 Hz...25 kHz -3 dB
THD+N............................................................. 0,007 % nominal
GENERAL
POWER SUPPLY
Mains voltage..........................................230 VAC +/-10% @ 50 Hz
Power consumption................................20 W
FADERSTART
(channel 3 t/m 5) .............................................. Maximum ratings: 48V/ 0,1A; 3,5 mm jack
SIZE AND WEIGHT
Front.......................................................483 x 355 mm (W x H) = 19”, 8HE
Cutout.....................................................448 x 334 mm (W x H)
Depth......................................................107 mm
Weight.....................................................5.6 kg Net.
