8
Installation
SPL2(TS) and SPL3(TS) user manual
EN
OVERLOAD Connection for LED's or solid-state-relays, for external signalling of the
OVERLOAD situation (20 V / 10 mA).
WARNING Connection for LED's or solid-state-relays, for external signalling of the
WARNING situation (20 V / 10 mA).
LIVE MODE OK Output for driving the switched power for the "live"-amplifiers (normally this
output is “on” (+20 V / 10 mA DC), in the case of sanction, current is
switched off.
SANCTION ACTIVE In SPL2 mode it is possible to apply an additional sanction when the
threshold is exceeded by more than 14dB. If this function is required pins 6
and 7 must be shorted.
MAINS Mains connection cable. The SPL limiters operate at 220 .. 240 V AC. The
limiter has a built-in self recovering fuse which does not need to be
replaced.
