36
To
account for slower data
transfer
in
CMOS
devices,
the clock frequency
is again divided by two to
400kHz
when the CMOS data bus
is active.
The decoded address
'CMOS I/O' at M57-7
is set to
logic 1 during these
transfers,
so
a
400kHz square wave
appears at M57-11.
The
combined
effect of this
and the
800kHz
output
from
M57-15
is
to
'stretch' the
waveforms
of the
Phase
1 and 2
clock
outputs
(illustrated
in Fig. 3.36).
Thus
Phase
2
remains at logic
1
for V/2
cycles
of
the
normal
800kHz
operation,
allowing
more
time for CMOS
transfers.
M57-15
M57-11
[
M56-8
[
02
I
^
FIG. 3.36
TIMING DIAGRAM
OF
STRETCHED
TWO-PHASE
CLOCK
3.8.1.3
RAM/ROM
Circuit
The
6800
uses 3
Read-Only
Memory
chips (ROMs)
which contain
the program
necessary to
run the
instrument.
Each ROM is
able
to
store up
to
4096,
8-bit
'bytes'
of
program
information; grouped
in
program
modules. The
MPU accesses
a
byte by
placing
its address on
the
16-bit
Address Bus and
driving
the Valid
Memory
Address (VMA)
line
true
(logic-1).
The
information held
in that
particular
location is
then sent
back to the
MPU
via the
Processor
Data
Bus.
The
chip-select inputs
for the
RAM and ROM
are
decoded
from a
selection
of high-order
address
bits.
This
selection
determines
the
positions of
the RAM
and ROM
in the
memory map.
For example:
M30
is fed
from
A15.A13.A12 so
that it
covers the
memory locations
from
#F000 to
#FFFF
(Note that
since A14
is not
decoded M30
also
appears at #B000
to
#BFFF).
The processor
employs
1024 bytes
of
8-bit wide
Random
Access
Memory (RAM)
made
up
from two 1024
X
4-bit RAMs (M31/M36).
M31
and M36
are employed as
operating
memory
for scratch pad
operations
and storing
volatile
data (e.g.
Max,
Min). The
principal
location of the
RAM
is from #0000 to
#00FF. Since A8
and A9 are not
decoded there
are
images starting at #0100, #0200,
#0300.
A
further 256
bytes of
8-bit wide RAM
are made up
from two 256 x
4-bit RAMs
(M19/M20).
M19
and M20 are
backed up
by a battery to
privide the
non-volatile 'Calib-
ration'
and 'Zero'
memory.
Three
address bits
A12,
A14
and A15
are decoded
by M33
(pin
8)
to
enable
M19/M20,
but M29
(pin
6)
permits the memory
contents to be
changed
only
if
CAL
is selected, or
if the ZERO
section of the
memory is
addressed (A7
and A6
both
at logic-1).
The
read/write
control
line
R/W
from the
6800
is
gated
with
a
'Master
Clock
-f-
2'
signal to
provide
correct
timing,
and
the address
decodes
include
gating
with
VMA02.
An
instrument
po
wer up
is
detected
by
M60/M62
causing
an
initialization
RESET
signal
to
be fed to
the
MPU
via Q16.
(See
Fig. 3.38).
During a
power-up
or
power-down
(-t5V
supply
line
<+4.75V) a
signal
from
the
supply-level
detectors
prevents
RAMs
M 19
and
M20
from
being
overwritten by
holding
the
CS
(chip
select)
lines
low «0.2
volts)
via Q14
for a
period
of approx.
25mS
determined
by
R55/C32.
3.8.2
CMOS
Address
Decode
and
Input/Output
Circuits
(430329
sheet
2)
Information
is
transferred
to
and
from
CMOS
devices
via
the
CMOS
Data
Bus
during
periods
when the
signal
CMOS
J/0
is at
logic-1
(M33-6).
CMOS
I/O is
addressed
when
A15.A14.A11
is
true.
This
occurs
when
memory
locations
starting
at
#4100
(and
its
images)
are
selected.
The
transfer
of
data
between
the
Processor
Data
Bus
and
the
CMOS
Data Bus
takes
place at
400kHz, the
Read/
Write lines
selecting
the
direction
of the
information
through
the
tri-state
buffers M4,
M5
and M6.
In order
to
address the
various CMOS
input/output
devices, the
address
lines must
be
further decoded.
M32
is
a
1-of-10
decoder,
providing 5
addressable
drives;
M16
is a
dual
1-of-4
decoder
addressing
the
front
panel circuitry
and the
digital
elements of
the A-D
converter. A
summary
of the decoded
CMOS
address
signals is
given in
Fig. 3.39.
