David Clark XL-9V - Battery and Accessory Handling; Battery Insertion and Removal; Belt Clip Removal; Connector Insertion and Removal



19528P-85(11/02) 
BatteryInsertionandRemoval

CAUTION:Improperbatteryinsertionmaydamageunit.

Toremovethebatterycompartmentcover,pressdownontherecessandslidethecoverback.
Toinstallthebatterycompartmentcover,alignwiththerecessinthebatterycompartmentand
slidethecoverforwarduntilitsnapsintoposition(SeeFig.3).

Toinstallbattery,insertbackofbatteryintobatterycompartment,makingsuretopositionthe
smallerpositiveterminaloverthekeyingribsinthefrontofthebatterycompartment(SeeFig.4).
Presscontactendofbatteryfirmlyuntilbatteryisseatedinthebatterycompartmentfully.
Toremovebattery,liftuponthebackofthebatteryandslideoutofbatterycompartment.

 

























ConnectorInsertionandRemoval(Doesnotapplyto"13X"hardwiredmodel)


Fig.7
Fig.3



Fig.7

BeltClipRemoval
Fig.5


Fig.4

Fig.6
