Page 2 Sensor Mounting Shelf for Vantage Pro
T
OOLS
FOR
S
ETUP
✦
Medium Phillips screwdriver
I
LLUSTRATION
Here is an illustration of the sensor mounting shelf installed on the ISS:
Note:
This manual shows installation of the sensor mounting shelf before the
two round solar sensors have been attached to it. If you like, the solar sensors
can be mounted on the shelf before it is installed on the ISS. (Consult one of the
sensor manuals for instructions.)
Final leveling of the sensors should be done
after the ISS is mounted in its operating location.
Sensor
Mounting
Shelf
