Page 4 Sensor Mounting Shelf for Vantage Pro
A
NOTHER
I
LLUSTRATION
Here is an illustration of the shelf after the sensors have been mounted on it.
Detailed instructions for attaching the sensors are contained in their manuals.
(It makes no difference which sensor is mounted on right/left side of the shelf.)
UV and Solar Radiation Sensors
