Product Number: 6672 and 6673 Part Number: 07395.133
Sensor Mounting Shelf Rev B Manual (October 4, 2004)
Copyright © 2004 Davis Instruments Corp. All rights reserved.
'LDEOR$YHQXH+D\ZDUG&$
)D[
(PDLOLQIR#GDYLVQHWFRPZZZGDYLVQHWFRP
Sensor Mounting Shelf support tube holes
The following illustrations show the locations of the support tube holes in both the
black plastic and the white painted aluminum Sensor Mounting Shelf types. The instal-
lation procedure and mechanical performance of the different shelves are identical.
Aluminum Sensor Mounting Shelf support tube holes
Plastic Sensor Mounting Shelf support tube holes
Holes for Support Tube Screws
Three Holes for Sensor Screw
hree Holes for Sensor Screws
Holes for Support Tube Screws
Three Holes for Sensor Screw
hree Holes for Sensor Screws
