SPECIFICATIONS
TYPE DYM1P60FA DYM1P64FA
Dry weight (kg) 12 12
Engine type 4-stroke, OHV, single cylinder
Displacement (bore x stroke) 118 ccm, 60x42 mm 135 ccm, 64x42 mm
Max. torgue 6 Nm at 2 600 /min 7 Nm at 2 600 /min
Cooling system Forced, air
Lubrication system Forced, splash
Ignition system TCI
PTO shaft rotation Counterclockwise
TUNEUP SPECIFICATION
ITEM SPECIFICATION MAINTENANCE
Spark plug gap 0,028 – 0,031 in
(0,7 – 0,8 mm)
See page 14
Valve clearance (cold engine) IN: 0,06±0,02 mm
EX: 0,08±0,02 mm
See your authorized
dealer.
Other specifications No other adjustment needed.
