2
MOTOR
The pump is fitted with an integral synchronous permanent-magnet high
efficiency inverter controlled motor. The pump should be connected to a suitably
rated MCB or fuse.
Enclosure Class: IP42 Insulation Class: F Voltage: 1x240
OPERATING CONDITIONS
Pumped Liquid: Thin, clean, chemically non-aggressive liquids without solid
particles or fibres
0 0
Liquid Temperature: -10 C to +110 C
0
Max. Ambient Temperature: 10 - 50 C
Max Operating Pressure: 6bar
Installation: Pumps must be installed with the rotor shaft horizontal and vertical
water flow
H
L
W
Model
PUMP DATA
Dimensions (mm)
Power
(W)
Inlet/
Outlet
(”)
L W
DQA25/60DQA25/60
5-455-45 11 180180 130130128128
Weight
(kg)
H
33
