10
Operating Instructions
Using the Rear Storage Compartment
The rear storage compartment is opened using the key provided to you when you pur-
chased your e-bike. Insert the key and turn it to the right to open the compartment. Close
the case and turn the key in the opposite direction to lock the compartment again. You can
use this compartment to store the charger and associated cables, so you can
recharge your e-bike if it runs out of power. It can also hold a locking mechanism, such a u-
lock, for added security when parking your e-bike. The space provided is perfectly suited
for these purposes.
Opening the Seat Trunk
To open the seat trunk, insert the key into the lock on the left side of the e-bike just below
the seat. Turn it all the way to the right. The seat will snap open and pop up.
To close the seat trunk, make sure that there is nothing blocking the locking mechanism,
such as items you have placed in the storage compartment, and push the seat down with
force. You will hear a “click” sound when it is properly closed.
Parking and Locking your E-bike
When you want to park your e-bike for a short time, either when you have reached your
destination or are at home, follow these steps:
1. Stop the e-bike and position it as you want it.
2. Get o the e-bike, making sure to keep it balanced.
3. Stand to the side and slightly to the rear of the e-bike.
4. Hold the kickstand with one foot, and hold on to the e-bike by the rear basket
bracket.This bracket is made of metal and will hold the e-bike’s weight.
5. Pull the back of the seat up and towards you. The e-bike will move backwards.
The kickstand will hold the e-bike in place and anchor the bike.
6. Lock your e-bike to a bicycle locking post or other secure object through the rear
wheel frame or one of the metal frame components.
Warning
Do not let your e-bike drop or fall. The exterior may be damaged. The fall may damage
other components inside the e-bike, as well.
