Days Escape Lite - Technical Specifications; Dimensions and Weights; Propulsion and User Limits

11
Technical Specifications – Escape Lite Wheelchair
Propulsion Attendant
Self-Propelled
Seat Parameters
Seat Height - Front (from the ground) 510+/-5mm
510+/-5mm
Seat Height - Rear (from the ground) 490+/-5mm
490+/-5mm
Seat Width <on the outside of the tubes> 460mm
460mm
Seat Depth 410mm
410mm
Backrest Height (from the seat) 400mm
400mm
Footrest Length 400-560mm
400-560mm
Overall Dimensions
Overall Length (with footrests) 995mm
1056mm
Overall Length (without footrests) 750mm
800mm
Overall Width (open) 530mm
634mm
Overall Width (folded) 230mm
312mm
Overall Height 920mm
942mm
Chair Weight 12kg
15kg
User Weight
Standard 100kg
115kg
