Days Strider ST-1 - Scooter Parts and Controls Identification; Front View of the Scooter; Top Control Panel Layout; Back View of the Scooter

Instruction BookletST-1
Issue 1 02/04/2010
Figure 2 - ST-1 Top Control Panel Figure 3 - ST-1 Back View
IDENTIFICATION OF PARTS
5
Before attempting to drive this scooter on your own, it is important that you familiarize
yourself with the controls, and how to operate them.
Figure 1 - ST-1 Front View
Tiller Angle
Adjustment
Circuit
Breaker
Seat Rotation
Lever
Release Lever
Battery Pack Pin
Charging Socket
Horn Button
Thumb Lever
Main
Key Switch
Battery Gauge
Self-Diagnostic
Warning Light
Speed Dial Knob
Reflectors
Anti-Tip Wheels
Free-Wheeling
Lever
