This is how it looks after the
fi t m e n t o f t h e s p e a k e r
assembly from inside.
Take out the connector wire
(12) from the 3mm hole that
we have made manually in
t h e w h i t e p a p e r a n d n o w
connect it to the bluetooth module
female part (13).
12
13
The speaker assembly wire
(10) gets hidden inside the
Neck Curtain (11).
11
10
40
