Parts List and Assembly Diagram
Parts List
Part Description Qty
1 Screw 2
2 Lock Washer 2
3 Cap 2
4 Roller 2
5 Swivel Caster 2
6 Locking Swivel Caster 2
7 Lock Nut 4
8 Nut 1
9 Washer 1
10 Right Arm 1
11 Pedal Lock 1
12 Foot Pedal 1
13 Front Pawl 1
14 Spring 1
Part Description Qty
15 Pin 1
16 Lever 1
17 Press Plate 1
18 Bolt 1
19 Back Pawl 1
20 Spring 1
21 Riveting Plate 1
22 Limit Plate 1
23 Pin 1
24 Cotter Pin 1
25 Spring 1
26 Washer 1
27 Left Arm 1
28 Rubber Pad 1
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and
are not available individually as replacement parts.
To Next Page
