Circuit
Characteristics
4—4—
I I
I
I I
I I
I i I I I
INPUT
463X
Performance
Specifications
Frequency
response
20 Hz-20
KHz
±
1
dB
THD
0.2°/o
(unity gain)
Equivalent input noise
-85
dBv unweighted
(unity
gain)
Maximum input
18
dBv
to
soft
clipping
Maximum
output
18 dBv into
600 ohms
Input impedance
391 k-ohms, single-ended
Output impedance
22
ohms, single-ended
(designed to drive
600 ohms
or
greater)
KEY input
impedance
62 K-ohms
Threshold range
+ 10 to
-60
dBv
(OverEasy)
Attenuation
range
0-70
dB,
depending
on
input
level
and
slider
setting
Gain
(no
gating)
Unity
(rear
jack);
0-20
dB,
adjustable
(instrument
input)
Downward
expansion
ratio
Adjustable
from
none to 6:1,
front
slider
Attack
time
Approximately 1
ms,
program-
and
slider-dependent
Release
time
10-500
ms,
program-
and
slider-dependent
Power
requirements
100-120/220-240
V ac,
switchable;
50-60
Hz; 7 W
Notes
1}
Specifications
are subject to change.
2)
Ail voltages
are
rms
(root-mean-square).
3)
0
dBv
is
defined as 0.775
V
regardless of
load Impedance. Subtract
2.2
from the dBv
figure to
convert to dBV
(i.e.,
referred
to
1 V).
When
the load impedance
is 600
ohms,
this
particular dBv
is also Known
as "dBm."
4)
Noise figures
are
for
20
Hz-20
KHz.
5)
Attack time is
the
time required to restore
the
signal
to
654b of the input level
after It
has
gone above the
OverEasy
threshold;
release time is the time
required
for
the
signal
to be
reduced to 654b
of
Its final gated
level.
