DCA M1Q-FF-85 - Page 10

EXPLAINATION OF GENERAL VIEW
1 Handle Cover 26 Snap Washer
2
Pan Head Tapping Screw
ST4.2×19
27 Washer
3 Nut 28
Pan Head Screw M4×14
4
Pan Head Screw M4×20 (with
Spring and Flat Washers)
29 Needle Bearing HK0608
5
Pan Head Tapping Screw
ST4.2×16 (with Flat Washer)
30 Pin
6 Strain Relief 31 Eccentric Block
7 Cord Guard 32 Sleeve
8 Cord 33 Balance Block
9 Hex Wrench 34 Washer
10 Nameplate 35 Washer
11 Rear Cover 36 Grip Ring
12
Pan Head Tapping Screw
ST4.2×19
37 Washer
13 Capacitor 38 Washer
14
Pan Head Tapping Screw
ST2.9×10
39 Shifter
15 Coil Spring 40 Washer
16 Carbon Brush Holder 41 Eccentric Gear
17 Carbon Brush 42 Needle Bearing TN1
18 Trigger Switch 43 Washer
19
Pan Head Screw M5×25 (with
Spring and Flat Washers)
44 Washer
20 Handle 45 Snap Washer
21 Motor Housing 46 Blower Spigot
22
Pan Head Tapping Screw
ST3.5×9
47
Pan Head Tapping Screw
ST4.2×25
23 Baffle Plate 48 Washer
24 Stator 49 Gear Housing
25 Seal Pad 50 Blade Orbit Selector Lever
EXPLAINATION OF GENERAL VIEW
51 Spring 77 Stroke Rod
52 Retaining Sleeve 78 Slide Support
53 Switch for Sawdust Blower 79 Slide Groove
54 Grip Ring 80
Cross Recessed Countersunk
Head Screw M3.5×10
55 Sleeve 81
Pan Head Screw M4× 8 (with
Flat Washer)
56 Felt Washer 82 Positioning Pin
57 Seal Cover 83
Pan Head Screw M4×14
58 Ball Bearing 609SS 84 Guide Plate
59 Circlip for Hole 85 Spring
60 Armature Assembly 86 Pad
61 Ball Bearing 627ZZZC 87 Shim
62 Saddle Washer 88 Pin
63 Washer 89 Gear Housing Cover
64 Bracket 90 Pan Head Screw M4×14
65 Hex Nut 91 Safety Protector
66 Aluminium Base 92 Guide Roller Retainer
67 Inner Base 93 Snap Washer
68
Cross Recessed Countersunk
Head Screw M5×8
94 Shaft
69 Clamp Plate 95 Washer
70
Hex Socket Head Screw M6×16
96 Needle Bearing SCE
71
Lock Screw M6×12
97 Guide Roller
72 Oil-Retaining Bearing 98 Inductance
73 Oil-Retaining Bearing 99 Label
74 Washer 100 Long Wire
75 Shaft Cover 101 Middle Wire
76 Washer 102 Short Wire
-17- -18-
