These curves were obtained f rom volume and
pressure
readings taken at unit rnlet with the
filter
clean.
Standard and Hopper type units
To
select the
most
suitable unit
for
a
given
application:
1 Determine the
air
volume, in m3/h, needed
to entrain the dust.
2 Estimate
pressure
drop through
connected system
-
i.e. between
point
of
entrainment and unit inlet.
3
Assess
pressure
drop across
filter
prior
to
shaking, usually 50-1 00mm
W
G
4 The
sum of 2 and 3
=
W.G.
required
5 Consult
graph
for fan
performances
available.
Sack Tipping Units have K3
(1
5 kW)
fans
with modified
outlet to ensure adequate
face
velocities at the tipping hatch under normal
operating conditions
Typically, the exhaust
rate for the
UIVA
250STU is 1275m3/h
(750
cfm)
0593
