2. Fasi di installazione del prodotto (prima di procedere, assicurarsi
che la macchina sia spenta e che la spina sia scollegata dalla presa
di corrente)
2. Product installation steps (before installation, be sure to turn off the
switch and disconnect the power)
1). Install the mixing alex into the
mixing bowl
The outer hexagon hole of the stirring
shaft is fitted into the inner hexagon
hole of the motor shaft.
If it gets stuck in the assembly, rotate
the stirring shaft slightly to install it
smoothly.
5)Tighten the disc nut clockwise. 6)First, aim the top cover
lid clamping position at the
front notch of the fuselage
barrel, press down, hear a
"click", and install in place.
2)Attach the extruding pipe
to the mixing bowl
3)I
nstall extruding axle. 4)Install the disc and
extruding head
Use methodUse method
09
10
2. Product installation steps (before installation, be sure to turn off the
switch and disconnect the power)
1). Install the mixing alex into the
mixing bowl
The outer hexagon hole of the stirring
shaft is fitted into the inner hexagon
hole of the motor shaft.
If it gets stuck in the assembly, rotate
the stirring shaft slightly to install it
smoothly.
5)Tighten the disc nut clockwise. 6)First, aim the top cover
lid clamping position at the
front notch of the fuselage
barrel, press down, hear a
"click", and install in place.
2)Attach the extruding pipe
to the mixing bowl
3)I
nstall extruding axle. 4)Install the disc and
extruding head
Use methodUse method
09
10
1) Installare l’asse per impastare
sulla ciotola.
Il foro esagonale esterno
dell’albero della macchina si
innesta nel foro esagonale interno
dell’albero motore.
Se durante il montaggio si blocca,
ruotare leggermente l’albero della
macchina in modo che si installi
correttamente.
3) Installare l’asse di estrusione.
2) Applicare il tubo di estrusione
alla ciotola.
4) Installare il disco e la testina di
estrusione.
