DIGITAL CONTROL INCORPORATED
DigiTrak MFCB Operator’s Manual 13
Appendix A: System Specifications
The power requirements and environmental requirements for the DigiTrak Multi-Function
Cable Box and remote displays are listed below.
Power Requirements
Device (Model Number)
Operational Voltage
Operational Current
DigiTrak Multi-Function Cable Box
12–28 V
6 A max
DigiTrak Remote MFD Display (MFD)
12–28 V
3.2 W max
DigiTrak Remote F Series Display (FSD)
12–28 V
3.2 W max
DigiTrak Eclipse and F Series Cable Transmitter
(ECP, FC)
9–28 V
6 A max
DigiTrak Eclipse Steering Tool (SST)
9–28 V
6 A max
Environmental Requirements
Device
Relative
Humidity
Operating Temperature
System Working
Altitude
DigiTrak Multi-Function Cable Box
<90%
-4 to 140° F (-20 to 60° C)
Up to 6561 ft. (2000 m)
DigiTrak MFD Remote Display (MFD)
<90%
-4 to 140° F (-20 to 60° C)
DigiTrak F Series Remote Display (FSD)
<90%
-4 to 140° F (-20 to 60° C)
DigiTrak Eclipse and F Series
Transmitter (ECP, FC)
<100%
-4 to 180° F (-20 to 82° C)
DigiTrak Eclipse Steering Tool (SST)
<100%
-4 to 180° F (-20 to 82° C)
