DCS RF151 - Clearance Dimensions

7
INSTALLATION INSTRUCTIONS
PRODUCT DIMENSIONS
inches (mm)
A
Overall height of product * 33 3/4”–343/4” (857 – 883)
B
Overall width of product 147/8” (378)
C
Overall depth of product (excluding handles) 23 5/8” (600)
D
Height of chassis 33 5/8” (854)
E
Depth of chassis 211/2” (546)
F
Depth from front of chassis to door front 2 1/8” (54)
G
Thickness of door panel 15/8” (41)
H
Height of front grille panel 3” (76)
I
Height from top of door to top of chassis 3/8” (10)
J
Width of handle 8” (203)
K
Depth of handle 13/16” (30)
L
Height of handle 13/16” (30)
M
Height of adjustable feet 5/8” – 13/8” (16–35)
* Includes mounted feet.
CLEARANCE DIMENSIONS
inches (mm)
Overall height of cutout min. 341/2” (min. 876)
Overall width of cutout
Overall width of cutout
(with optional DCS side trim kit)
15” (381)
151/2” (394)
Depth of cavity ** min. 24” (min. 610)
** Depth dimension varies depending on individual installation.
