7
INSTALLING THE ANTI TIP DEVICE
FOR FREESTANDING INSTALLATIONS
21
1
2"
(54.6 cm)
"V" notches
in bracket
"V" notches
in bracket
Side of cabinet line
Figure 7
Front of cabinet line
Rear of cabinet line
Rear Leveling leg
Screw
Figure 7a
NOTE
When the oor mounted anti-tip bracket is used the mini-
mum adjusted height of the cabinet is increased by
3
8" (9 mm).
