Dea ADVANCE Series User Manual

33
ADVANCE XL WIRING DIAGRAM
J4
178 9 13 14 15 1610 11 124567123
19 18
21
20
OUT 1
IN 4 IN 3
MOT 1
IN 2 IN 1
COM
OUT 2
+24V_ST
CON1
CON2
CON2
CON4
+24VAUX
ENC (M1)
ENC A
+
ENC B
-
RG58
F1
POWER SUPPLY
230V~ 50Hz ±10%
H05VV-F 3x0,75mm
2
F
N
230V
25V
TX RX
COM
N.C.
N.O.
N.O.
START
2 x 0,5 mm
2
PHOTO 1
OPEN GATE
WARNING LIGHT
24V max 5W
COURTESY LIGHT
2 x 0,5 mm
2
2 x 0,5 mm
2
2 x 0,5 mm
2
2 x 0,5 mm
2
FLASHING LIGHT
24V max 5W
2 x 0,5 mm
2
CON5
2 x 0,5 mm
2
FLASH
CON3
(2x1,5 mm
2
+ 4x0,5 mm
2
)
PLUG CABLE/ADV (cod. 397321)
INTERNAL WIRING SET BY THE FACTORY
EXTERNAL WIRING SET BY THE INSTALLER
MOT 1
MOT 1
FLASH
Plug
Motor Terminal Block
ENC
ENC A
+
ENC B
-
YELLOW
GREY
BROWN
WHITE
GREEN
PINK
YELLOW
GREY
BROWN
WHITE
GREEN
PINK
