Dea ghost 200/EN User Manual

GHOST 200
Operating instructions and warnings
10
4.5.5 Adjustment
Inordertoinstallstandardproductsnoadjustmentisrequi-
red;whiletoinstallGHOST200withtheaccessory“mechanical
stopart.218”youwillonlyhavetopositionthestopblocksby
unscrewingtheirfixingscrews;thenpositionthemcorrectly,have
themrunalongtheappositeslotsandtightenupthetwoscrews
again(seeF6page32)
WARNING Alltheotheradjustment/settingoperationsbeyond
theadjustmentoftheoilflowaremadebythemanufacturer.
Tamperingwiththesesettingsmaycausemalfunctionand/or
situationsofrisktopeople,animalsandproperty.Refrainfrom
performing any operations not authorised by DEA System.
4.5.6 Maintenanceandrepair
Goodpreventivemaintenanceandregularinspectionensure
longworkinglife(seealso“Warranty”).Consultthe“TROUBLE-
SHOOTING”table(seepage9)wheneveranomaliesareobser-
vedinordertofindthesolutiontotheproblemandcontactDEA
Systemdirectlywheneverthesolutionrequiredisnotprovided.
Theinspection/maintenanceoperationstoberoutinelysche-
duledinthe“completeautomationmaintenancehandbook”are:
INTERVENTION TYPE PERIODICITY
cleaning of external 6 months
checking of screw tightening 6 months
checking of release
mechanism operation
6 months
check that water flows out properly
from the foundation box
6 months
greasing of articulated joint 1 year
WARNING Beforedoinganymaintenanceoperationtakeoff
thefoundationboxlid(byunscrewingthetwofixingscrews;
seeF5page30);thislidoffersprotectionagainsttheriskof
scissormovementduetothepresenceofmovinglevers.Once
themaintenanceoperationiscompletedplacebackimmedia-
telythisprotection. 
A6
WARNING Allinstallation,maintenance,cleaningorrepair
operations on any part of the system must be performed
exclusively by qualified personnel with the power supply
disconnectedworkinginstrictcompliancewiththeelectrical
standardsand regulationsinforce inthenationofinstalla-
tion. 
A3
WARNING TheuseofsparepartsnotindicatedbyDEASy-
stemand/orincorrectre-assemblycancreaterisktopeople,
animalsandpropertyandalsodamagetheproduct.Forthis
reason,alwaysuseonlythepartsindicated byDEASystem
andscrupulouslyfollowallassemblyinstructions.
A7
4.6 Training
Afterinstallationandsetting,thecorrectoperationofthecom-
pleteautomatismmustbecarefullyillustratedtothefinaluser.
GHOST 200 gate operator requires careful instruction on
thereleasemechanism (see “Enclosures”) and onthespecific
maintenanceschedule(seePoint4.5.6.).
WARNING AwarenessoftheoperationofGHOST200key-
releasemechanism(seeF8Page32)isessentialforallusers
oftheautomatismbecause failuretousethedevice quickly
duringemergenciescanjeopardisepeople,animalsandpro-
perty.EnclosureItotheseinstructions,whichtheinstalleris
requiredtodelivertothefinaluser,illustratesoperationand
canbedetached.
4.7 Inappropriate use
Chapter“4.4Appropriateconditionsofuse”describesthe
conditionsforwhichtheproducthasbeendesignedandtested.
Theproductmustneverbeusedforotherpurposes.
WARNING Theuseoftheproductunderunusualconditions
notforeseenbythemanufacturercancreatesituationsofdan-
ger,andforthisreasonalltheconditionsprescribedinthese
instructionsmustberespected.
A1
WARNING Under no circumstances must the product be
usedinexplosiveatmospheresorsurroundingsthatmayprove
corrosiveanddamagepartsoftheproduct.
A2
5 SPARE PARTS LIST
Thelistofsparepartsthatcanbeordered(Pages28and
29)isadetailedlistthataccompaniestheexplodedviewofthe
productandmustbeusedtoorderspareparts.
Thefollowingdatamustalwaysbeprovidedwhenordering
spareparts:
• thecodeoftheproduct(seenontheproductlabel;seeF7,
Page32),
• thepart’spositionnumberintheexplodedview,
• ifavailable,theproduct’spurchasedatemaybeuseful in
somecases.
6 COMPLETE CLOSING ASSEMBLY
Thischapterillustratesthetypicalinstallationofacomplete
automationforthepurposeofinformingandassistingtheinstal-
lerintheselectionofthevariouspartstobeusedincompliance
with Machinery Directive (2006/42/CE) and European Safety
Standards(EN12453-EN12445)forgateinstallation.
Thedataprovidedinthischapterareneithercompletenor
exhaustive,andDEASystemdeclinesallliabilityforanyerrors,
omissionsorinaccuraciesthatmayoccur.
6.1 Minimum level of protection provided by the sa-
fety edge
Amongthemostseriousriskstobeconsideredwhenauto-
matingofaswinggateistheriskofcrushingbetweentwowings
orbetweenonewing and its stop duringclosing.Regulations
prescribetheadoptionofoneofthefollowingtypesofcontrols
againstsuchrisksdependingontheuseforeseenforthegate.
Anappropriatetypeofoperatingcontrolboardmustbeused
accordingtothegatetypeandaccordingtoitsusage,asprovided
forbythequotedregulations(see“OPERATINGCONTROL”table).
6.2 Risk of crushing in the opening area
Theriskofbeingcrushedcanalsoariseintheareabetween
thegateopeningandthewallorfencebehindit.F9onPage
32providesthemeasurementsthatmustbeobservedwhenever
measuresarenottakentolimittheimpactforceorwhenever
presencedetectionsystemsarenotused.
6.3 Impact in the opening/closing area
Inordertoavoidbeingcrushedbythegatewingintheclo-
singarea,installapairofphotocells(A)(recommendedheight:
500mm)inordertodetectthepresenceofthetestparallelepiped
(B)(height:700mm)positionedasshowninF10onPage32.
Note.Thepresencedetectiontestsampleisaparallelepiped
with3sideswithlight-colouredreflectingsurfacesand3sides
withdark-coloured,opaquesurfaces.
Inorder to furtherreducetheriskof impact withthegate
wingintheopeningarea,anextrapairofphotocells(C)(re-
commendedheight:500mm)canbeinstalledforthedetection
ofthepresenceofthetestparallelepiped(D)(height:700mm)
positionedasshowninF10onPage32.
