Dea GHOST 200 Series User Manual

GHOST 200
Operating instructions and warnings
11
RESPONSIBILITIES OF THE INSTALLER
Remember that anyone who sells and/or motorises doors/gates becomes the manufacturer of the automatic door/gate
machineandmustthereforeprepareandpreserveatechnical folderthatcontainsthefollowingdocuments(seeMachinery
DirectiveEnclosureV):
• Assemblydrawingoftheautomaticdoor/gate;
• Electricalconnectionandcontrolcircuitwiringdiagram;
• Riskanalysisincluding:alistoftheessentialsafetyrequirementsprovidedinMachineryDirectiveEnclosureI;alistoftherisks
posedbythedoor/gateandthedescriptionofthesolutionsadopted.
• Keeptheseoperatinginstructionsinasafeplacetogetherwiththeinstructionsforalltheothercomponents;
• Preparetheseoperatinginstructionsandgeneralsafetywarnings(byfillingintheseoperatinginstructions)andhandacopy
tothefinaluser;
• Fillinthemaintenancehandbookandhandacopytothefinaluser;
• DrafttheCEdeclarationofconformityandhandacopytothefinaluser;
• FillinthecompleteCElabelorplateandapplyittothedoor/gate.
Note:Thetechnicalfoldermustbepreservedforinspectionbythecompetentnationalauthoritiesforatleasttenyearsfrom
thedateofconstructionoftheautomaticdoor/gate.
“OPERATING CONTROL” table
Type of use
Type of control
Informed users
(private areas)
Informed users
(public areas)
Uninformed users
Person-present control Pushbutton control Pushbutton control with key
The person-present control is
not possible
Pulse control with the gate in
sight
Force limitation
or
presence detectors
Force limitation
or
presence detectors
Force limitation
and photocells
or presence detectors
Pulse control with the gate
not in sight
Force limitation
or
presence detectors
Force limitation
and photocells
or presence detectors
Force limitation
and photocells
or presence detectors
Automatic control
(i.e. control with
timed closing)
Force limitation
and photocells
or presence detectors
Force limitation
and photocells
or presence detectors
Force limitation
and photocells
or presence detectors
10
1 5 6 7 8 9
2 3
4
“EXAMPLE OF TYPICAL INSTALLATION” picture
Pos. Description
1 102 Lux key switch
2 Remote-control
3 Pilly 60 column
4 Safety edge
5 Electric lock
6 FLIC/rad digital
keypad
7 104 Lux series
photocells
8 GHOST
9 Control board
10 Lumy flashing light
