Dea GHOST 200 Series User Manual

GHOST 200
Operating instructions and warnings
7
GHOST 200
Underground electro-mechanical operator for swing gates
Operating instructions and warnings ENGLISH
INDEX
Declaration by manifacturer ..........................1
OVERVIEW .......................................................7
1 PRODUCT CONFORMITY ..................................7
2 RESIDUAL RISK WARNINGS ............................7
3 MODELS AND CONTENTS OF THE PACKAGE ...8
4 OPERATING INSTRUCTIONS ...........................8
4.1 Product description ................................8
4.2 Technical data ........................................8
4.3 Labelling information ............................8
4.4 Appropriate conditions of use ..............8
4.5 Instructions for risk-free operation .......9
4.5.1 Transport – 9
4.5.2 Installation, assembly
and disassembly – 9
4.5.3 Starting – 9
4.5.4 Use – 9
4.5.5 Adjustment – 10
4.5.6 Maintenance and repair – 10
4.6 Training ...............................................10
4.7 Inappropriate use ................................10
5 SPARE PARTS LIST ..........................................10
6 COMPLETE CLOSING ASSEMBLY ...................10
6.1 Minimum level of protection
provided by the safety edge ................10
6.2 Risk of crushing in the opening area ..10
6.3 Impact in the opening/closing area ....10
Example of typical installation ............27
ANNEXES
- Instructions for the final user
- Terms of warranty
OVERVIEW
SCOPEOFTHEINSTRUCTIONS
Theseinstructionswerepreparedbythemanufacturerand
areanintegralpartoftheproduct.Theoperationsdescribed
areintendedforadequatelytrainedandqualifiedoperatorsand
mustbecarefullyreadandpreservedforfuturereference.
Chapters “2 RESIDUALRISKWARNINGS”and “4 OPERA-
TING INSTRUCTIONS” contain all the information that DEA
Systemprovidesin order fortheproductto constantly satisfy
theEssentialSafetyRequirementsprescribedbytheMachinery
Directive(EuropeanDirective2006/42/CE).
Readthesechapterscarefullybecausetheycontainimpor-
tantinstructionsforsafeinstallation,useandmaintenanceand
importantwarningsregardingtheresidualrisksremainingeven
afterallthesafetydevicesandmeasuresdescribedhavebeen
applied.
Theproductisdesignedforinstallationincompleteclosing
systems subject to specific legislation. Chapter 6 “COMPLETE
CLOSINGASSEMBLY”providesusefulinformationfortherespect
oftheEssentialSafetyRequirementsforspecialtypesofclosing.
1 PRODUCT CONFORMITY
DEA System guarantees the conformity of the product to
EuropeanDirectives2006/42/CEregardingmachinerysafety,
2004/108/CEelectromagneticcompatibilityand 2006/95/CE
lowvoltageelectricalequipment.DEASystemalsoenclosesthe
manufacturer’sDeclarationofConformitywiththeseinstructions
(seeDirective2006/42/CEArt.4,paragraph2).
2 RESIDUAL RISK WARNINGS
Readthesewarningscarefully;thefailuretorespect
thefollowingwarningscancreaterisksituations.
WARNING Usingthisproductunderunusualconditionsnot
foreseenbythemanufacturercancreatesituationsofdanger,
andforthisreasonalltheconditionsprescribedinthesein-
structionsmustberespected.
A1
WARNING Under no circumstances must the product be
usedinexplosiveatmospheresorsurroundingsthatmaypro-
vecorrosiveanddamagepartsoftheproduct.
A2
WARNING Allinstallation,maintenance,cleaningorrepair
operations on any part of the system must be performed
exclusively by qualified personnel with the power supply
disconnectedworkinginstrictcompliancewiththeelectrical
standardsand regulationsinforce inthenationofinstalla-
tion. 
A3
WARNING Startingtheoperatorwiththeleverunitsetonthe
releasedpositionmayseverelyinjureyourarmsandlegs.Be
extremelycareful!Releasetheleverunitonlyifreallyneces-
sary:Ifthereisapowersupplyfailuredisconnectmanuallythe
powersupplyoftheoperatorbyusingtheappositeswitch;in
thisway,whenthepowerisbackyouwillbeabletostartthe
operatoronlyafterblockingtheleverunitagain.
A4
WARNING All other adjustment/setting operations beyond
theadjustmentoftheoilflowaremadebythemanufacturer.
Tamperingwiththesesettingsmaycausemalfunctionand/or
situationsofrisktopeople,animalsandproperty.Refrainfrom
performinganyoperationsnotauthorisedbyDEASystem.
A5
WARNING Beforedoinganymaintenanceoperationtakeoff
thefoundationboxlid(byunscrewingthetwofixingscrews;
seeF5page31);thislidoffersprotectionagainsttheriskof
scissormovementduetothepresenceofmovinglevers.Once
themaintenanceoperationiscompletedplacebackimmedia-
telythisprotection. 
A6
WARNING UsingsparepartsnotindicatedbyDEASystem
and/orincorrectre-assemblycancreaterisktopeople,ani-
mals and property and also damage the product. For this
reason,alwaysuseonlythepartsindicated byDEASystem
andscrupulouslyfollowallassemblyinstructions.
A7
WARNING Awareness of the operation of the key-release
mechanism(seeF8Page32)isessentialforallusersofthe
automatism because the failure to use the device quickly
duringemergenciescanjeopardisepeople,animalsandpro-
perty.EnclosureItotheseinstructions,whichtheinstalleris
requiredtodelivertothefinaluser,illustratesoperationand
canbedetached. 
A8
