EN-4
7 INPUTS AND OUTPUTS DESCRIPTION
The tables below provide a description of the functioning of all possible selections for both the inputs and the outputs on the NET_EXP
board. Also refer to the table confi guration parameters.
INPUTS
SELECTION DESCRIPTION
NONE Not used.
START
N.O. input start. In case of action, this results in the opening or closing. It may function in “inversion”
(P049=0) or “step-by-step” (P049=1) modality.
PED.
N.O. pedestrian start. In case of action, this results in the partial opening of the gate. The adjustment of the
pedestrian pace can be set with P043.
OPEN N.O. input open. In case of action, this results in the partial opening of the gate.
CLOSE N.O. input close. In case of action, this results in the closing of the gate.
OPEN_PM Dead man N.O. input open The gate opens for the amount of time in which the button is pressed.
CLOSE_PM Dead man N.O. input close The gate closes for the amount of time in which the button is pressed.
ELOCK_IN
Electric lock activation N.O. input. In case of action, this leads to the activation of the “LOCK” output of the
board, see P062.
PHOTO 1
Photoelectric cell 1 N.C. input. See P050 to select the operation mode. If this is not used, bridge out the
connection.
PHOTO 2
Photoelectric cell 2 N.C. input. See P051 to select the operation mode. If this is not used, bridge out the
connection.
SAFETY 1
Sensitive edge 1 N.C. input. See P067 to select the operation mode. If this is not used, bridge out the
connection.
STOP (SAS INPUT)
N.C. contact. (SAS INPUT): If connected to WARN_FIX/SAS OUTPUT of a second control unit, causes the “bank
door” to operate (disabling the opening of the second door until the fi rst is not fully closed).
Stop N.C. input. In case of action, this stops the movement during any manoeuvre. If this is not used, bridge
out the connection.
FCA1 Motor 1 opening end stop N.C. input If not used, disable the input with the corresponding parameter.
FCA2 Motor 2 opening end stop N.C. input If not used, disable the input with the corresponding parameter.
FCC1 Motor 1 closing end stop N.C. input If not used, disable the input with the corresponding parameter.
FCC2 Motor 2 closing end stop N.C. input If not used, disable the input with the corresponding parameter.
SAFETY 2
Sensitive edge 2 N.C. input. See P068 to select the operation mode. If this is not used, bridge out the
connection.
OPEN_INT
Starts the operation and enables the green light ignition (arrival at open gate) only for the internal traffi c
light. Meanwhile, if the OPEN_EXT command is given, this books the next operation and the green light of the
external traffi c light turns on at the end of the Automatic Closing Time (ACT).
OPEN_EXT
Starts the operation and enables the green light ignition (arrival at open gate) only for the external traffi c
light. Meanwhile, if the OPEN_INT command is given, this books the next operation and the green light of the
internal traffi c light turns on at the end of the Automatic Closing Time (ACT).
AUX_IN Input for the control of the AUX_OUT output.
SAFETY INHIBITION
N.C. input SAFETY inhibition. When open, it causes the by-pass of the SAFETY inputs, which are ignored even
if activated.
