Dea REV Series Operating Instructions And Warnings

EN-3
2 PRODUCT DESCRIPTION
Models and contents of the package
The name REV identies a series of electromechanical operators for sliding gates with different features as to motor and control
board power supply voltage, capacity, mechanical adjustment of force, electronic clutch and built-in limit switch. All automated models
involve the use of advanced control units (NET series) equipped with anti-crushing sensor, built-in 433 MHz radio receiver, speed control
and slow down in opening and closing. The REV models are intended primarily for residential / condominium and Semi-intensive/inten-
sive use depending on the duty cycle foreseen for the automation.
REV is completed by a set of accessories listed in the “PRODUCT ACCESSORIES” table (page I-7).
REV is composed of a mechanical gear motor which rotates the driving gear; This gear, coupled to the rack properly installed on the
gate, converts the circular motion of the gear motor into rectilinear motion thus allowing the movement of the gate on its own guide.
Inspect the “Contents of the Package” (Pic. 1) and compare it with your product for useful consultation during assembly.
Transport
REV is always delivered packed in boxes that provide adequate protection to the product, however, pay attention to all information
that may be provided on the same box for storage and handling.
3 TECHNICAL DATA
REV220 - REV220/M -
REV220/IB
REV220/RF - REV220/RFM
- REV220/RF/IB
REV24/F - REV24/M -
REV24/IB
Motor power supply voltage (V) 230 V ~ ±10% (50/60 Hz) 24 V
Absorbed power (W) 500 250
Max Thrust (N) 900 1200 450
Work cycle (leaf L=8m)
up to 1000 Kg 27 cycles/hour 36 cycles/hour
up to 1400 Kg 22 cycles/hour 31 cycles/hour
Maximum n° of operations in 24
hour (leaf L=8m)
up to 1000 Kg 270 300 300
up to 1400 Kg 220 250 250
Built-in capacitor (µF) 14 12,5 -
Operating temperature range (°C) -20÷50 °C
Motor thermal protection (°C) 150 °C -
Opening speed (m/min) 10 12
Weight of product with package (Kg) 18
Sound pressure emitted (dBA) < 70
Protection degree IPX4
OPERATOR
CONTROL BOARD
NET24N
Power supply (V) 230 V ~ ±10% (50/60 Hz)
Rated power transformer (VA) 250 VA (230/22V)
Fuse F1 (A) (transformer) 2A
Batteries 2x 12V 1,3A
Fuse F2 (A) (batteries input) 15A
24V operators outputs 1x 10A
Warning: The above values are calculated by taking the maximum power
supplied by the respective processors. In absolute terms, the maximum
current for each output should not exceed 10A when using a single motor
and 7A when using 2 motors.
Auxiliaries power supply output 24 V
(24V_AUX + 24V_ST =
max 200mA)
Safety devices power supply output
“Warning” output 24 V
max 15 W
Electric lock output
24V
max 5W or max
1 art. 110
Flashing light output 24 V
max 15W
Operating temperature range (°C) -20÷50 °C
Receiver frequency 433,92 MHz
Transmitters type of coding
HCS x-code - HCS rolling
code - Dip-switch
Max remote controllers managed 100
NET230N
Power supply (V) 230 V ~ ±10% (50/60 Hz)
Fuse F2 (A) 5A
Fuse F1 (A) 160mA
230V operators outputs 2x 500W (or 1x 600W)
Auxiliaries power supply output 24 V ~
(24V_AUX + 24V_ST
= max 200mA)
Safety devices power supply output 24V
“Warning” output 230 V ~ max 150W
Electric lock output
max 1 art. 110 or 24V
output max 5W congurable
230V Flashing light output 230 V ~ max 40W
24V Flashing light output
24 V
max 100mA (for led
ashing light) art. LED24AI or
open gate warning light/courtesy
light
Operating temperature range (°C) -20÷50 °C
Receiver frequency 433,92 MHz
Transmitters type of coding
HCS x-code - HCS rolling code -
Dip-switch
Max remote controllers managed 100
