4
DECADE transmitters inc. is not responsible for any loss of profit or
laws violation during the utilisation of their transmitters.
Industry Canada legislate the use of FM transmitters for Canada uses.
The LX-75 series are not certified by the FCC so it is not legal to sell or use these
products in USA.
E) Technical specifications
Refer to appendices, Technical specifications of LX-75 series.
SECTION 2
INSTALLATION
A) Introduction
Installation of a DECADE FM transmitter includes the following steps: 1) receiving
inspection; 2) mounting in a rack or on a shelf; 3) connection of the AC supply and
audio source; location, installation and connection of the antenna (optional).
B) Receiving inspection
Check the transmitter packaging for any damage that could have occurred in the
shipping. If you find any damage on the transmitter, keep the packaging for claiming
purposes with the freight company. Any damage should be noted on the receiving slip
at the time of delivery and the freight company advised within 5 workable days
following the delivery of damaged units.
C) Connections
After installation of the transmitter in a rack or on a shelf, plug the AC wall adaptor
(furnished) in the AC receptacle on the back panel, of the transmitter and connect the
wall adaptor to a 120 V, 60 Hz wall AC socket. An RCA audio cable is also furnished
for linking your audio source to the LX-75 audio inputs.
